Your complete reference for woven label fold styles and laundry labels — mastering construction techniques, laundry symbol types, and professional care label design. Fifteen years of manufacturing wisdom condensed into practical guidance for designers, brand builders, and production teams who demand precision.
Woven Label Fold Styles
Choose the right fold and your labels will look professional and feel comfortable. Choose wrong and you'll end up with rough edges, poor attachment, or labels that don't work with your garment design.
Here are the seven fold styles we use most, with simple explanations of when each one works best.
1 Straight Cut simple and versatile⚠ only style compatible with iron-on or peel & stick backing
The most straightforward option with no folding required. Great for beginners since it works with sew-on, iron-on, or adhesive backing. Simple to understand and versatile enough for any project — from basic clothing labels to complex multi-color designs.
2 Center Fold sewn into seam, popular for shirt neck
The most popular choice for t-shirts and dress shirts. Gets sewn right into the neck seam where it stays put and looks professional. Perfect for shirt necks because the fold creates two sides — brand on front, care instructions on back.
3 Loop Fold sewn into seam, garment interior labels
Similar to center fold but without the sharp crease, making it softer and more flexible. Gets sewn into side seams or interior locations where the label won't be seen. Great for garment interiors because it's comfortable and moves with the fabric naturally.
4 End Fold professional designer favoritepreferred for printed cotton labels
The cleanest, most professional look you can get. Both side edges fold behind so you never see any raw cuts. Professional designers love this because it looks perfect and feels smooth — no rough edges to irritate skin or snag fabric. End folds are recommended for natural fiber materials with unsealed edges such as printed cotton clothing labels.
5 Mitre Fold sewn into seam, popular for shirt neck
A clever design that works as both a label and a hanging loop. Gets sewn into the neck seam like center fold, but the angled construction creates a built-in hanger. Popular for shirt necks when you want the label to double as functional hardware for hanging the garment.
6 Manhattan Fold t-shirt sleeve or pocket hem tags
Perfect for those small hem tags you see on t-shirt sleeves or inside jacket pockets. Only folds the top edge, keeping it lightweight and low-profile. Great for t-shirt sleeves and pocket hems because it adds minimal bulk while still looking clean and professional.
7 Book Cover Fold popular beanie edge fold-over labels
Both top and bottom edges fold behind for complete edge protection. Often used on beanie edges where the label folds over the rim and both sides might show. Popular for beanie edge labels because it's durable and looks good from either side when folded over.
🏆 Pro Tips
Essential measurements for professional results:
1. The standard seam allowance (amount of label material inserted into a seam) is ¼"
2. The standard amount of label material folded back on end folds, top of Manhattan fold, or top and bottom of book cover folds is ¼"
3. Most professional designers choose end fold over straight cut when sewing woven labels down flat. End folds hide the cut edges and provide a clean, itch-free finish
Laundry Symbols for Care Labels
Care symbols help people wash their clothes properly without ruining them. There are five basic symbols that always appear in the same order: washing → bleaching → drying → ironing → professional cleaning.
Learn these symbols and you can create labels that work anywhere in the world.
1. Washing — Basin Control System
The basin icon governs water-based cleaning. Internal numbers specify maximum safe temperatures in Celsius. Underline bars reduce agitation intensity. Cross-outs prohibit water contact entirely.
Wash 30°C
Cold, normal cycle
Wash 40°C
Warm, normal cycle
Wash 60°C
Hot, normal cycle
Wash 70°C
Normal cycle, energy-saving method
Wash 95°C (Boil)
Maximum temp; white cotton/linen
Gentle 30°C
Mild cycle, reduced agitation
Gentle 40°C
Delicate cycle
Gentle 60°C
Mild cycle at 60°C
Very Gentle 30°C
Wool / minimum agitation
Very Gentle 40°C
Wool cycle at 40°C
Hand Wash
Max 40°C, no machine
Hand Wash (Ambient)
Hand wash at room temp
Do Not Wash
No water washing
Understanding Underline Codes
The bar code runs throughout all care symbols: no bars = standard processing, single bar = reduced intensity, double bars = minimal intensity. Learn this pattern once and you can decode any care instruction system worldwide.
2. Bleaching — Triangle Permission System
The triangle controls chemical whitening permissions. Empty triangles allow all bleaching agents. Internal markings restrict chemistry options.
Any Bleach
Chlorine & oxygen safe
Non-Chlorine Only
Oxygen bleach safe
Do Not Bleach
No bleach of any kind
3. Drying — Square Method Control
Squares govern moisture removal methods. Internal circles mean machine tumbling with dot-coded temperatures. Internal lines indicate natural air-drying orientations.
Tumble Dry Normal
Max 80°C exhaust
Tumble Dry Low
Max 60°C exhaust
Do Not Tumble Dry
No machine drying
Line Dry
Hang on line/hanger
Flat Dry
Lay flat to dry
Drip Dry
Hang wet, don't wring
Drip Flat Dry
Lay flat while soaking wet
Line Dry in Shade
Hang dry, avoid sunlight
Flat Dry in Shade
Lay flat in shade
Drip Line Dry in Shade
Hang wet in shade
Drip Flat Dry in Shade
Lay flat wet in shade
4. Ironing — Temperature Regulation
Iron symbols control heat application. Dot quantity inside indicates maximum safe sole-plate temperatures for pressing and steaming.
Iron Low (110°C)
Synthetics
Iron Medium (150°C)
Wool, silk, blends
Iron High (200°C)
Cotton, linen
Iron Low, No Steam
120°C max, no steam
Do Not Iron
No ironing or pressing
5. Professional Care — Chemical Specification
Circle symbols indicate professional cleaning requirements. Internal letters specify approved solvents: P for perchloroethylene systems, F for hydrocarbon-only processes, W for water-based professional methods.
Dry Clean (P)
Perc & all solvents
Dry Clean P (Gentle)
Mild perc cleaning
Dry Clean (F)
Hydrocarbon only
Dry Clean F (Gentle)
Mild hydrocarbon cleaning
Do Not Dry Clean
No professional cleaning
Wet Clean (W)
Professional wet clean
Wet Clean (Gentle)
Mild professional wet cleaning
Wet Clean (Very Gentle)
Very mild wet cleaning
Do Not Wet Clean
No professional wet cleaning
Real-World Care Label Designs
Here's how care symbols look on actual labels. Both examples show the symbols in the correct order: washing → bleaching → drying → ironing → professional care. This order is the same worldwide.
1. Standard Cotton Garment Label
This shows a typical cotton garment label. Fiber content goes at the top (required by law for US sales), then country of origin, then care symbols with English instructions below. The ¼″ seam allowance at top gets sewn into the garment and won't show on the finished label.
2. Luxury Silk Blend Label
This label shows delicate fabric care requirements. Silk and polyester blends need gentler treatment than cotton: hand wash only, no machine drying, and dry cleaning with special solvents. Different fabric types need different care symbols, so always check what your fabric needs. This label also uses the same ¼″ seam allowance as the cotton example.
🇪🇸 US Market Requirements
Federal Trade Commission mandates English-language care instructions — symbols alone don't satisfy legal requirements for US sales. Both examples above include English translations below care symbols to ensure compliance. International markets accept ISO/GINETEX symbols as sufficient. For brands selling in both domestic and export markets, combining English instructions with standard symbols covers all requirements.
Manufacturing Questions Answered
What woven label fold types do experienced manufacturers recommend?
After 15+ years in manufacturing, we work with seven proven fold types: Straight Cut (flat construction with sealed edges), Center Fold (our workshop workhorse — creates dual panels with a sharp crease), Loop Fold (flexible design without permanent creasing), End Fold (premium approach with tucked sides for luxury finish), Mitre Fold (45-degree angular construction that doubles as functional hardware), Manhattan Fold (single-wrap technique for lightweight applications), and Book Cover Fold (double-wrap method for complete edge protection). Each serves distinct manufacturing needs and garment categories.
Why do manufacturers prefer center fold construction for woven labels?
Center fold dominates our production floor because it solves multiple challenges simultaneously. The crease creates natural separation between branding space and compliance information. Raw edge management is straightforward — both get captured in standard garment construction. Production efficiency is excellent since sewing machines handle the ¼-inch allowances consistently. We've manufactured millions of center fold labels since 2008, and they perform reliably across every garment type from delicate silk to heavy denim.
How should I interpret care symbols on professionally-made woven labels?
Care symbols follow strict international protocols using five universal icons: basin symbols control washing temperatures and agitation levels, triangular markings govern bleaching permissions, square symbols dictate drying methods and heat settings, iron graphics specify pressing temperatures and steam use, circular symbols indicate professional cleaning requirements. Cross-outs mean prohibition. Underline bars signal reduced intensity — single bar means gentle handling, double bars mean ultra-gentle treatment. This system works globally and we've been applying it correctly since our founding.
What distinguishes Manhattan fold from book cover fold in woven label construction?
These are both hem tag solutions but serve different manufacturing priorities. Manhattan fold wraps only the top edge behind the main panel — this creates lighter construction perfect for ultra-thin applications like premium t-shirt hems or delicate cap brims. Book cover fold wraps both top and bottom edges, creating complete perimeter protection but adding material thickness. Choose Manhattan when weight matters and only one side shows. Choose book cover when both surfaces might be visible or when you need maximum edge protection. We've produced both styles extensively since 2008.
Do woven labels need care symbols for US market compliance?
US Federal Trade Commission rules require written English care instructions — symbols alone don't satisfy legal requirements. However, ASTM D5489-96c approved symbols can replace written words if used correctly. International ISO/GINETEX symbols cannot substitute for English text on US-market woven labels. Our recommendation after years of compliance work: combine clear English instructions with appropriate symbols. This dual approach satisfies US regulations while providing international recognition. For export-only products, ISO symbols alone work fine.
Put Our Workshop Experience to Work
From center fold workhorses to luxury end fold construction — we've mastered every technique in this guide since 2008. Let our manufacturing expertise bring your label designs to life with precision and consistency.
